AT128
120° Ultra-High Resolution Long-Range Lidar
Ranging Capability
210 m @10% Reflectivity
Point Rate
1,536,000 pts/s (Single Return)
Field of View
120° x 25.4°
Angular Resolution
0.1° (H) x 0.2° (V)
Power Consumption
13.5 W
Pixel Resolution
1200 x 128
Dimensions
136 x 114 x 49 mm
Weight
940 g
AT512
120° Ultra-High Resolution Ultra-Long-Range Lidar
(Designed for ADAS Series Production Vehicles）
Ranging Capability
300 m @10% Reflectivity
400 m Maximum
Point Rate
12,288,000 pts/s (Single Return)
Field of View
120° x 25.6°
Angular Resolution
0.05° (H) x V0.05° (V)
Power Consumption
25 W
Pixel Resolution
2400 x 512
Dimensions
160 x 110 x 45 mm
ATX
ATX Ultra-Compact 120° Ultra-High Resolution Long-Range Lidar
(Designed for ADAS Series Production Vehicles）
Ranging Capability
200 m @10% Reflectivity
300 m Maximum
Point Rate
1,200,000 pts/s (Single Return)
Field of View
120° x 20°
HFOV 120° ~ 140°
VFOV 20° ~ 25.6°
Angular Resolution
0.1° (H) x 0.1° (V) Finest
Power Consumption
8 W
Dimensions
100 x 100 x 30 mm
Minimum Surface Window 25 mm
Weight
360 g
ET25
Ultra-Thin 120° High-Resolution Long-Range Lidar
(Designed for ADAS Series Production Vehicles）
Ranging Capability
250 m @10% Reflectivity
225 m @10% Reflectivity (With Windshield)
Point Rate
3,700,000 pts/s (Single Return)
Field of View
120° x 25°
Angular Resolution
0.1° (H) x V0.1° (V）
Power Consumption
12 W
FT120
Fully Solid-State 75° Ultra-Wide View Short-Range Lidar
Ranging Capability
25 m @10% Reflectivity
Point Rate
192,000 pts/s (Single Return)
384,000 pts/s (Dual Return)
Field of View
100° x 75°
Angular Resolution
0.625° (H)x 0.625° (V)
Power Consumption
12 W
Pandar128
128-Channel 360° High-Performance Long-Range Lidar
Ranging Capability
200 m @10% Reflectivity
Point Rate
3,456,000 pts/s (Single Return)
6,912,000 pts/s (Dual Return)
Field of View
360° x 40°
Angular Resolution
0.1° (H) x 0.125° (V)
Pandar64
64-Channel 360° High-Performance Long-Range Lidar
Ranging Capability
200 m @10% Reflectivity
Point Rate
1,152,000 pts/s (Single Return)
2,304,000 pts/s (Dual Return)
Field of View
360° x 40°
Angular Resolution
0.2° (H) x 0.167° (V)
Pandar40P
40-Channel 360° High-Performance Long-Range Lidar
Ranging Capability
200 m @10% Reflectivity
Point Rate
720,000 pts/s (Single Return)
1,440,000 pts/s (Dual Return)
Field of View
360° x 40°
Angular Resolution
0.2° (H) x 0.33° (V)
Pandar40M
40
Channel
0.3 ~ 120 m (10% reflectivity)
Range
40° (-25° ~ +15°)
Vertical FOV
0.2° (10 Hz) , 0.4° (20 Hz)
Horizontal Resolution
Finest at 0.33°
Vertical Resolution
QT128
128-Channel 360° Ultra-Wide View Short-Range Lidar
Ranging Capability
20 m @10% Reflectivity
Point Rate
1,152,000 pts/s (Single Return)
Field of View
360° x 105°
Angular Resolution
0.4° (H) x 0.4° (V)
QT64
64-Channel 360° Ultra-Wide View Short-Range Lidar
Ranging Capability
20 m @10% Reflectivity
Point Rate
576,000 pts/s (Single Return)
Field of View
360° x 104°
Angular Resolution
0.4° (H) x 1.45° (V)
OT128
Next-Generation Flagship 360° High-Performance Long-Range Lidar
Ranging Capability
200 m @10% Reflectivity
230 m Maximum
Point Rate
3,456,000 pts/s (Single Return)
6,912,000 pts/s (Dual Return)
Field of View
360° x 40°
Angular Resolution
0.1° (H) x 0.125° (V)
Power Consumption
29 W
XT32 / XT32M / XT16
High-Precision Zero Blindspot 360° Mid-Range Lidar
Range
0.05 ~ 120 m
Range Precision
0.5 cm 1σ
Accuracy
±1 cm
Field of View
360° (H) x 31° (V)
Angular Resolution
0.18° (H) x 1° (V) @10Hz
Point Rate
640,000 pts/s (Single Return)
Dimensions
Top Diameter 100.0 mm
Bottom Diameter 103.0 mm
Height 76.0 mm
Weight
800 g
Handheld
200 m (82% diffuse reflectivity,
15000 ppm*m methane gas concentration)
Detection Range
5 (actual) ppm*m
Sensitivity
±10% (100 ~ 50000 ppm*m)
Measurement Accuracy
5 ms
Response Time
0.76 kg
Weight (with battery and sight)
Drone-Mounted
400 m (82% diffuse reflectivity,
15000 ppm*m methane gas concentration)
Detection Range
5 (actual) ppm*m
Sensitivity
±10% (100 ~ 50000 ppm*m)
Measurement Accuracy
5 ms
Response Time
<600 g
Weight
